PS5 Southbridge Chip CXD90061GG BGA Reballing Steel Mesh – 90×90mm
Keep your PS5 motherboard repairs running smoothly with this precision-cut 90×90mm direct-heating BGA reballing steel mesh designed specifically for the PS5 southbridge chip CXD90061GG. Whether you're a professional board-level repair technician or an experienced hobbyist, this stencil delivers accurate solder ball placement for reliable, clean reball results every time.
Key Features
- Exact Fitment: Engineered specifically for the PS5 CXD90061GG southbridge/IC chip — no guesswork, no misaligned pads.
- 90×90mm Direct-Heating Design: Compatible with standard direct-heating reballing stations for fast, efficient soldering sessions.
- BGA Package Support: Precisely laser-cut apertures match the BGA ball grid array layout of the CXD90061GG chip.
- High-Quality Steel Construction: Durable stainless steel mesh withstands repeated heating cycles without warping or deformation.
- New Condition: Supplied brand new — ready for immediate professional use straight out of the package.
- No High-Concern Chemicals: Free from high-concern chemical substances for safer workshop handling.
Product Specifications
- Stencil Size: 90 × 90 mm
- Type: Direct-Heating BGA Reballing Steel Mesh
- Compatible Chip: PS5 Southbridge CXD90061GG
- Package Type: BGA (Ball Grid Array)
- IC Type: Drive IC
- Condition: New
- Country of Origin: Made in Mainland China
Who Is This For?
This steel mesh stencil is ideal for electronics repair professionals, console repair shops, and skilled technicians performing motherboard-level repairs on the PlayStation 5. It ensures accurate solder ball deposition on the CXD90061GG chip, saving time and improving first-attempt success rates.
Related Products You May Find Useful
- Electromagnetic Induction Tester – Coil & Circuit Fault Detector
- Air Compressor Pressure Gauge 0-10/0-12/0-25 Bar | DIY Tool
Learn more: OSHA on eye and face protection
Frequently Asked Questions
Q: What PS5 chip is this BGA reballing steel mesh designed for?
A: This 90×90mm direct-heating stencil is specifically designed for the PS5 motherboard southbridge chip CXD90061GG. The aperture pattern matches the BGA ball grid array layout of that exact chip for precise, reliable solder ball placement.
Q: Is this stencil compatible with standard reballing stations?
A: Yes. The 90×90mm size fits most standard direct-heating BGA reballing stations and fixtures commonly used in professional electronics and console repair workshops.
Q: How many times can this steel mesh stencil be reused?
A: The stainless steel construction is designed to withstand multiple heating cycles without warping or deforming, making it suitable for repeated professional use. Proper cleaning and storage between uses will extend its lifespan.
