Take your WEMOS D1 Mini projects to the next level with this compact 8×8 LED Matrix Shield (V1.0.0). Designed as a plug-and-play expansion board, this module delivers crisp digital signal output control across a full 64-dot grid — perfect for makers, hobbyists, and electronics enthusiasts who want a reliable, low-profile display solution.
Key Features
- Seamless WEMOS D1 Mini Compatibility – Designed specifically as a shield that plugs directly onto your WEMOS D1 Mini board with no extra wiring required.
- 8×8 Dot Matrix Display – Control 64 individual LEDs for scrolling text, animations, icons, and custom patterns via digital signal output.
- SMD Package Design – Surface-mount components keep the board compact and lightweight, ideal for space-constrained enclosures and wearable projects.
- Wide Operating Temperature – Rated from -40°C to +80°C, making it suitable for a broad range of indoor and outdoor maker applications.
- Digital Signal Output Controller – Clean, reliable signal handling ensures consistent LED performance with minimal programming overhead.
- Customizable – Adaptable for a wide variety of DIY electronics projects including clocks, scoreboards, notification displays, and IoT dashboards.
- Brand New Condition – Every unit ships in new condition, ready for immediate integration into your project.
Specifications
| Version | V1.0.0 |
| Matrix Size | 8 × 8 (64 dots) |
| Compatible Board | WEMOS D1 Mini |
| Output Type | Digital Signal Output |
| Package Style | SMD (Surface Mount Device) |
| Operating Temperature | -40°C to +80°C |
| High-Concern Chemicals | None |
| Condition | New |
| Country of Origin | Made in Mainland China |
What Can You Build?
This shield is ideal for DIY electronics projects of all kinds:
- Scrolling text message boards
- Wi-Fi connected notification displays
- Digital clocks and countdown timers
- Retro-style game displays
- IoT sensor dashboards
- Custom animations and pixel art
