LiFePO4 BMS 1S 3.2V 7A Charging Board | Short Circuit Protection

LiFePO4 BMS 1S 3.2V 7A Charging Board – Smart Battery Protection Module

Keep your LiFePO4 battery cells operating safely and efficiently with this compact 1S 3.2V 7A Battery Management System (BMS) / PCM charging board. Engineered for reliability, this SMD-packaged protection circuit guards your battery against short circuits, over-charge, over-discharge, and thermal extremes — all with built-in self-recovery, so there's no need to manually reset after a fault event.

Whether you're building a DIY power bank, a custom battery pack, or repairing a mobile device, this BMS board delivers professional-grade protection in a compact form factor. Made in Mainland China.

Key Features

• 1S LiFePO4 Compatible: Designed specifically for single-cell 3.2V LiFePO4 battery configurations.
• 7A Continuous Charge/Discharge Rating: Handles everyday charging and load demands with ease.
• Short Circuit Protection: Instantly cuts power upon detecting a short circuit, protecting both the battery and connected devices.
• Self-Recovery Function: Automatically resets after a protection event — no manual intervention needed.
• Temperature Protection: Monitors cell temperature and cuts off current when unsafe thermal thresholds are reached, preventing overheating.
• Over-Charge & Over-Discharge Protection: Keeps the cell within safe voltage limits for maximum cycle life.
• SMD Package: Compact surface-mount design for easy integration into tight enclosures and custom builds.
• Wide Operating Temperature Range: Rated from -40°C to +85°C for versatile use across environments.
• No High-Concern Chemicals: Clean construction — no hazardous substances of concern.

Specifications

What's in the Box

• 1 × LiFePO4 BMS 1S 3.2V 7A PCM Charging & Protection Board

Related Products You May Like

• Electromagnetic Induction Tester – Coil & Circuit Fault Detector
• Air Compressor Pressure Gauge 0-10/0-12/0-25 Bar | DIY Tool

Learn more: ENERGY STAR product efficiency guidance

Frequently Asked Questions

Q: What is a LiFePO4 BMS charging board and what does it do?

A: A Battery Management System (BMS) — also called a PCM (Protection Circuit Module) — is a small electronic board that monitors and protects a lithium battery cell during charging and discharging. This 1S 3.2V 7A BMS board specifically manages a single LiFePO4 cell, preventing damage from short circuits, over-charging, over-discharging, and excessive temperature swings. It also features self-recovery, meaning it automatically resets itself after a protection event without any manual reset required.

Q: Is this BMS board compatible with standard LiFePO4 cells only, or can it work with other lithium chemistries?

A: This board is designed and optimized specifically for LiFePO4 (Lithium Iron Phosphate) cells with a 3.2V nominal voltage. LiFePO4 cells have different charge/discharge voltage thresholds compared to standard lithium-ion (3.7V) or lithium-polymer cells, so using this BMS with a different chemistry is not recommended and may result in improper protection behavior.

Q: What does the self-recovery feature mean in practice?

A: When the BMS detects a fault — such as a short circuit or an out-of-range temperature — it automatically disconnects the battery to prevent damage. With the self-recovery feature, once the fault condition clears (e.g., the short is removed or the temperature returns to a safe range), the board automatically reconnects without you needing to press a reset button or replace any components.

Q: Can this board be used in mobile phone battery repair or DIY battery pack projects?

A: Yes. This BMS board is well-suited for mobile device battery repair, custom single-cell LiFePO4 power packs, small energy storage projects, and other electronics DIY builds that use a 3.2V LiFePO4 cell and require up to 7A of charge/discharge current.
