Build Your Own FM/AM Radio – The Ultimate Electronics Learning Kit
Take your electronics skills to the next level with this hands-on FM/AM Radio DIY Soldering Kit by LOTHYE. Designed for students, hobbyists, and electronics enthusiasts, this all-in-one kit walks you through the complete process of assembling a fully functional FM and AM radio from individual components — making it an ideal project for school classes, maker workshops, or self-directed learning.
⚠️ Note: This kit is intended for buyers with basic circuit assembly experience. We guarantee all components are in excellent condition prior to shipment; however, successful assembly depends on the builder's experience and skill. Please read all instructions thoroughly before beginning. Batteries are not included.
Why Build a Radio?
A radio receiver may be compact, but it packs in a remarkable array of fundamental electronic circuits — making it one of the best educational projects you can tackle. Inside this kit, you'll work with:
- High-frequency & intermediate-frequency amplifiers
- Audio voltage & power amplifier stages
- Frequency conversion circuit
- Tuning & automatic sine wave oscillation circuits
- Detection circuit & automatic gain control (AGC)
- Volume control circuit
Mastering these circuits gives you a solid, real-world foundation for understanding and troubleshooting a wide range of electronic devices in the future.
Key Features
- Dual-band reception: Supports both FM and AM broadcast bands
- High sensitivity: Picks up stations clearly with excellent signal reception
- CD1691 integrated circuit chip: Reliable signal processing for stable performance and crisp, clear audio output
- Low power consumption: Efficient design that's easy on batteries
- Complete component set: Includes all electronic components, PCB circuit board, casing, schematic diagram, and step-by-step assembly instructions
- Hands-on soldering practice: Perfect for developing and refining PCB soldering skills
What's in the Box
- All required electronic components (resistors, capacitors, transistors, coils, IC chip, etc.)
- Printed circuit board (PCB)
- Plastic casing / housing
- Circuit working principle guide & assembly instructions
Batteries not included. Minor color differences between product images and actual item may occur.
Made in Mainland China.
