Dual Channel PWM Pulse Frequency Signal Generator
Take precise control of your electronics projects with this Dual Channel PWM Signal Generator. Featuring fully independent XY dual-system channels, this compact SMD module lets you generate square wave and rectangular pulse signals with adjustable frequency and duty cycle — perfect for engineers, hobbyists, and makers who need reliable, repeatable waveform outputs.
Key Features
- Dual Independent Channels: Two fully separate output channels (X and Y) for generating simultaneous or independent PWM signals.
- Wide Supply Voltage: Operates from 3.3V to 30V, making it compatible with a broad range of power supplies and microcontroller setups.
- Adjustable Frequency & Duty Cycle: Fine-tune your square wave or rectangular signal output to exact specifications for your circuit or test bench.
- Wide Operating Temperature: Rated from -40°C to 80°C for reliable performance in demanding environments.
- Compact SMD Module Design: Space-saving surface-mount design integrates easily into breadboards, PCBs, and DIY electronics setups.
- No High-Concern Chemicals: Manufactured without high-concern chemical substances for safer handling.
- Brand New Condition: Ships as a single, brand-new unit ready for immediate use.
Specifications
- Channels: 2 (Dual System – X & Y)
- Supply Voltage: 3.3V – 30V DC
- Signal Type: Square Wave / Rectangular Pulse (PWM)
- Duty Cycle: Adjustable
- Package Type: SMD Module
- Operating Temperature: -40°C to 80°C
- Quantity: 1 Module
- Condition: New
Who Is This For?
This PWM signal generator is ideal for electronics engineers, DIY enthusiasts, robotics builders, and students who need a versatile, adjustable waveform source for circuit testing, motor speed control, LED dimming, servo control, and countless other applications.
Made in Mainland China.
