DIY FM AM Radio Kit CF210SP – Soldering Practice Circuit Board

Build Your Own FM/AM Radio – The Ultimate Soldering & Electronics Learning Kit

The CF210SP DIY FM AM Radio Kit is a hands-on electronics assembly project designed for students, hobbyists, and aspiring engineers who want to develop real-world circuit building and soldering skills. This two-band radio covers FM (76–108 MHz) and AM (525–1605 kHz), giving you a fully functional radio you assemble yourself from scratch.

⚠️ Please Note Before Purchasing: This kit is intended for buyers with prior circuit assembly and soldering experience. While all components are tested and in excellent condition prior to shipment, successful assembly depends on the builder's skill and attention to detail. Please read all instructions carefully before starting. Battery is NOT included.

Why Build a Radio?

The radio receiver is one of the most comprehensive learning platforms in electronics. Despite its compact size, it incorporates a wide range of fundamental circuits, including:

• High-frequency amplifier circuit
• Intermediate frequency (IF) amplifier
• Audio voltage & power amplifier (TDA2822 IC)
• Frequency conversion circuit
• Tuning circuit
• Automatic sine wave oscillation circuit
• Detection circuit
• Automatic gain control (AGC) circuit
• Volume control circuit

Mastering these circuits builds a strong foundation for understanding, designing, and troubleshooting a wide variety of electronic devices.

Key Features

• ✅ Dual-Band Reception: FM 76–108 MHz & AM 525–1605 kHz
• ✅ High-Quality Audio: TDA2822 amplifier IC delivers clear, crisp sound
• ✅ Beginner-Friendly Design: Simple circuit layout with a high assembly success rate
• ✅ Excellent Selectivity: Strong station separation for clear reception
• ✅ Educational Value: Covers core electronic principles used across countless device types
• ✅ 100% Brand New Components: All parts are new and quality-checked before dispatch
• ✅ Complete Kit: Includes all electronic components and the PCB (battery not included)

Specifications

• Model: CF210SP
• Type: DIY Assembly Module Kit
• FM Frequency Range: 76–108 MHz
• AM Frequency Range: 525–1605 kHz
• Amplifier IC: TDA2822
• Condition: Brand New
• Quantity: 1 Set
• Made in: Mainland China

Who Is This Kit For?

This kit is perfect for electronics students in school or vocational training programs, hobbyists looking to sharpen their PCB soldering technique, and makers who want a rewarding, functional DIY project. It's an ideal gift for anyone passionate about electronics, engineering, or hands-on learning.
