Direct Heating BGA Reballing Stencil – RX 470 / 480 / 570 / 580 / 590 Series GPU
Give your AMD Radeon graphics card a second life with this precision-engineered direct heating BGA reballing stencil. Designed for GPU rework technicians and repair enthusiasts, this stencil ensures perfectly aligned solder balls every time — no guesswork, no misalignment. Whether you're servicing a failing RX470, RX480, RX570, RX580, or RX590, this stencil is your go-to tool for a clean, professional reflow or reball job.
Made in Mainland China.
Compatible GPU Part Numbers
- 215-0910052
- 215-0876406
- 216-0886164
- 215-0876204
- 215-0876184
- 215-0910038
Key Features
- Direct Heating Design: Place directly over the GPU die — no need to remove the chip before applying solder balls.
- Precision Laser-Cut: Holes are precisely aligned to match BGA pad layouts on AMD Polaris-series GPUs (RX 470 / 480 / 570 / 580 / 590).
- Durable Stencil Material: Engineered to withstand repeated heating cycles without warping or distortion.
- Time-Saving: Speeds up the reballing process significantly compared to manual placement methods.
- New Condition: Each stencil ships brand new, ready for immediate use.
- Package Type: BGA — single stencil per order.
What's in the Box
- 1× Direct Heating BGA Reballing Stencil (compatible with RX470, RX480, RX570, RX580, RX590)
Who Is This For?
This stencil is ideal for laptop and desktop GPU repair technicians, electronics rework professionals, and advanced DIY hobbyists who perform BGA soldering and reballing on AMD Radeon graphics cards. It pairs perfectly with standard reballing stations and hot air rework equipment.
