BGA Direct Heating Reballing Stencil – 90×90mm for 11th Gen Intel CPUs
This precision-engineered 90×90mm BGA direct heating reballing stencil is designed for professional laptop motherboard repair technicians. Compatible with a wide range of 11th Generation Intel Core CPUs, this stencil ensures accurate solder ball placement for reliable, clean reballing results every time.
Compatible CPU Models
- Intel Core i9-11900H – SRKT7
- Intel Core i7-11850H – SRKT4
- Intel Core i7-11800H – SRKT3
- Intel Core i5-11500H – SRKT2
- Intel Core i5-11400H – SRKT1
- Intel Core i5-11260H – SRKT0
Key Features
- Direct Heating Design: Allows hot air or infrared rework stations to apply heat directly through the stencil for faster, more uniform ball placement.
- 90×90mm Format: Precisely sized to match the BGA footprint of Intel 11th Gen H-series processors.
- High Precision Laser-Cut Holes: Ensures consistent solder ball alignment across every pad for professional-grade results.
- Durable Stainless Steel Construction: Withstands repeated use and high rework temperatures without warping or deforming.
- BGA Package Compatible: Fully compatible with standard BGA reballing processes and solder balls.
- Condition: Brand new.
Specifications
- Stencil Size: 90 × 90 mm
- Type: Direct Heating BGA Reballing Stencil
- Package Type: BGA
- Application: Laptop / Computer CPU reballing
- Quantity: 1 stencil per order
- Condition: New
- Made in Mainland China
Who Is This For?
Ideal for professional electronics repair technicians, laptop motherboard rework specialists, and hobbyist repairers who work with Intel 11th Gen H-series CPUs. Whether you are performing a single repair or handling high-volume board-level rework, this stencil delivers the accuracy and repeatability you need.
