Direct Heat BGA Reballing Stencil – SAK-TC1797 & SAK-TC1796 (90×90mm)
Achieve precise, professional-grade BGA reballing results with this 90×90mm Direct Heat Stencil designed specifically for SAK-TC1797, SAK-TC1797-512F180E AC, and SAK-TC1796-256F150EBE chips. Engineered for accuracy, this stencil ensures perfect solder ball placement every time — making it an essential tool for electronics repair technicians, rework specialists, and hobbyists alike.
Key Features
- Chip Compatibility: Purpose-built for SAK-TC1797, SAK-TC1797-512F180E AC, and SAK-TC1796-256F150EBE ICs
- Size: 90×90mm — optimized for direct heat reballing workflows
- Direct Heat Design: Allows hot air or infrared heat to be applied directly through the stencil for fast, clean reballing
- High-Precision Apertures: Laser-cut holes ensure uniform, correctly sized solder balls for reliable connections
- Durable Construction: Made from quality stainless steel for long-lasting, repeated use
- Condition: Brand new
- Package Type: SMD-compatible
- No Hazardous Chemicals: Free from high-concern chemical substances
Who Is This For?
This stencil is ideal for PCB repair technicians, electronics rework professionals, and advanced DIY enthusiasts who need reliable, chip-specific BGA reballing tools. Whether you're working on automotive ECU boards, industrial control units, or embedded systems using the SAK-TC1796 or SAK-TC1797 processors, this stencil delivers consistent, repeatable results.
What's in the Box?
- 1× Direct Heat BGA Reballing Stencil (90×90mm)
Made in Mainland China.
