CNMAWAY Linear Actuator Electric Motor – Versatile, Quiet & Powerful
The CNMAWAY DC Linear Actuator is a precision-engineered gear motor designed for smooth, reliable linear motion across a wide range of home, industrial, and automation applications. Available in 12V and 24V configurations with stroke lengths from 50mm to 500mm and force ratings from 100N to 1500N, this actuator adapts effortlessly to your specific project requirements.
Made in Mainland China with a robust aluminum alloy body and drip-proof IP54 protection, it operates quietly (under 42 dB) across ambient temperatures from -20°C to +75°C — making it an excellent choice for both indoor and outdoor installations.
Key Features
- Multiple Voltage Options: 12V DC, 24V DC, 36V DC, and 48V DC — choose the right fit for your system
- Wide Force Range: 100N / 300N / 500N / 700N / 1000N / 1200N / 1500N to match light and heavy-duty demands
- Flexible Stroke Lengths: 50mm, 100mm, 150mm, 200mm, 250mm, 300mm, 350mm, 400mm, 450mm, 500mm
- Variable Speed: 4 / 6 / 10 / 15 / 20 / 35 / 60 / 90 mm/s for precise control
- Self-Locking: ~80% self-locking force — holds position securely without continuous power
- Low Noise Design: Operates at less than 42 dB for quiet, unobtrusive performance
- IP54 Protection: Drip-proof rating keeps internal components safe from moisture and dust
- Permanent Magnet Brush Motor: Efficient, dependable power delivery rated at up to 30W
- Aluminum Alloy Construction: Lightweight yet strong housing for longevity
- Wide Temperature Range: Operates reliably from -20°C to +75°C
- CE Certified: Meets European safety and electromagnetic compatibility standards
Stroke Length Reference Guide
| Stroke | Retracted Length | Extended Length |
|---|---|---|
| 50mm | 155mm | 205mm |
| 100mm | 205mm | 305mm |
| 150mm | 255mm | 405mm |
| 200mm | 305mm | 505mm |
| 250mm | 355mm | 605mm |
| 300mm | 405mm | 705mm |
Technical Specifications
- Rated Power: 20W (Max 30W)
- Current Draw: 1–2A continuous
- Motor Type: Permanent Magnet Brush (Gear Motor)
- Protection Rating: IP54 (Drip-proof)
- Efficiency: IE2
- Material: Aluminum Alloy
- Noise Level: <42 dB
- Operating Temperature: -20°C to +75°C
- Battery Included: No
- Wireless: No
- Certification: CE
- Country of Origin: Made in Mainland China
Common Applications
- Window and skylight openers
- Electric beds and adjustable furniture
- TV consoles and entertainment lifts
- Massage and reclining chairs
- Industrial automation equipment
- Solar panel tracking systems
- Agricultural and greenhouse automation
Looking for other useful tools and accessories? Check out our Air Compressor Pressure Gauge – DIY Tool or the Electromagnetic Induction Tester – Coil & Circuit Fault Detector for more workshop essentials.
Learn more: OSHA on eye and face protection
Frequently Asked Questions
Q: What voltage options are available for this linear actuator electric motor?
A: This DC linear actuator is available in 12V, 24V, 36V, and 48V DC configurations, giving you flexibility to integrate it into a wide range of electrical systems — from small DIY projects to larger industrial or home automation setups.
Q: How do I choose the right stroke length and force (N) rating for my application?
A: Stroke length determines how far the actuator extends — choose a stroke that matches the required movement distance in your application (e.g. 100mm for a compact window opener, 300mm+ for furniture lift systems). Force ratings range from 100N (lighter tasks) up to 1500N (heavy-duty loads). Match the Newton rating to the weight or resistance the actuator needs to move. If in doubt, choose a higher force rating for a margin of safety.
Q: Is this linear actuator waterproof or suitable for outdoor use?
A: The actuator carries an IP54 drip-proof protection rating, meaning it is protected against dust and low-pressure water splashes from any direction. It is suitable for semi-exposed outdoor environments such as greenhouse window openers or covered installations. For full submersion or heavy rain exposure, additional weatherproofing measures are recommended.
Q: Does the linear actuator hold its position when power is off?
A: Yes. The self-locking mechanism retains approximately 80% of its rated holding force when unpowered, keeping the actuator securely in position without requiring continuous electrical input. This is particularly useful for furniture, window openers, and solar panel positioning applications.
