10pcs HFD4 SMD DIP Signal Relay – 3V 5V 12V 24V Variants

HFD4 Series SMD & DIP Signal Relays – 10-Piece Pack

Stock your workbench with this convenient 10-piece assortment of HFD4 series signal relays, available in both SMD (surface-mount) and DIP (through-hole) configurations. Compatible models include HFD4/3-SR, HFD4/4.5-SR, HFD4/5-SR, HFD4/9-SR, HFD4/12-SR, and HFD4/24-SR, making this pack ideal for electronics engineers, hobbyists, and repair technicians who need reliable switching components across a range of coil voltages.

Made in Mainland China.

Key Features

• Wide Voltage Range: Available in 3V, 4.5V, 5V, 9V, 12V, and 24V coil voltage options to suit diverse circuit designs
• SMD & DIP Packages: Choose surface-mount or through-hole variants depending on your PCB layout requirements
• General Purpose Use: Suitable for signal switching, automation circuits, consumer electronics, and control boards
• International Standard Compliance: Built to internationally recognised contact load, protection, and operating standards
• 10-Piece Quantity: Generous pack size ensures you have spares on hand for prototyping or production runs
• No High-Concern Chemicals: Clean construction with no restricted or hazardous substances of concern

Specifications

Who Is This For?

These relays are a go-to component for PCB designers, electronics repair professionals, and DIY enthusiasts working on automation systems, microcontroller projects, signal routing boards, and more. Whether you're prototyping a new design or restocking your components drawer, this 10-piece HFD4 relay pack offers excellent versatility and value.
